TATRA 815

Tatra 815 trucks for sale. Buy a fabled Czechoslovakian heavy truck. We can make a Tatra 815 truck road-legal. Tatra 815 VVN 26 265 8x8.R for sale Flatbed all-terrain truck designed to transport people and cargo up to a maximum weight of 12,000 kg. On paved roads, it will tighten a trailer with a maximum towable weight of 45,000 kg (50,000 kg), and in the field, 15,000 kg. A direct follower of Tara 813. Technical and tactical data Cargo space: - length: 6 250 mm - width: 2 410 mm - side height: 1 150 mm - height under tarpaulin: 2 055 mm Engine: - arrangement in V at an angle of 90 ° - supercharged, multi-fuel (diesel, kerosene, petrol 90.96 + diesel, always of course in a certain ratio) - firing of cylinders: 1 8 5 10 3 7 6 11 2 9 4 12 - engine capacity: 19004 ccm Winch: - 85 meters of steel rope with a diameter of 23.6 mm - tensile force 117.7 kN TATRA 815 VT 26 265 8x8.1 R The T-815 VT 8x8 military tractor is a four-axle car with permanent all-wheel drive. When overcoming difficult terrain, it is possible to change the tire overpressure while driving. It has a built-in attachment for working with a snow plow, a bulldozer blade and is equipped with a winding device for pulling out. The tractor is equipped with a twelve-cylinder, supercharged, multi-fuel, air-cooled engine. It has a four-door cabin, in its middle part there are two more seats located in the opposite direction, which can be divided into a temporary bed arrangement. The makeshift bed can be hung above the front seats. The platform grate is adapted to support the constant load needed to tow heavy trailers. Specifications: Make, type of vehicle T-815 VT 8 x 8 Standby weight 15,700 kg Payload 10,000 kg Total vehicle weight 25,700 kg Crew weight 600 kg Maximum trailer weight in the field 15,000 kg on public roads with a prescribed load of 9,400 kg Tyre size: 10.00 R20 Proportion of curb weight for front axles 2 x 4,600 kg rear 2 x 3 250 kg Proportion of total weight on front axles 2 x 5,775 kg rear 2 x 7 075 kg proportion of total weight with prescribed load on the front axle 2 x 6 425 kg rear 2 x 6 425 kg Car length 9,340 mm Width max. 2,500 mm Do not load the height of the car over the hatch. 3,030 mm do not load over the sail. 3,650 mm Clear height 410 mm Height of the towing device axis above the front road 965 mm rear 910 mm Wheelbase between first and second axle 1,650 mm between the second and third axles 2 970 mm between the third and fourth axles 1 450 mm Wheelbase front 2,044 mm rear 1 988 mm Engine type T 3-930-51 Engine type four-stroke, supercharged, multi-fuel, with direct fuel injection Number of cylinders 12 Drilling x stroke 120 x 140 mm Engine displacement 19,000 cm3 Maximum engine power 235 / 2,200 kW / min-1 Maximum torque 1,295 / 1,400 N.m / min -1 16: 1 compression ratio Cooling by air Friction clutch, single-disc, hydraulic control with pneumatic booster The transmission has 10 forward gears and 2 reverse gears. In addition to the first 2 and 2 reversals, the other stages are secured by synchronization Additional transmission two-speed, descending, with wheels in constant engagement. Shifting is performed by a gear clutch. Wheels rim size 11,25-21 divided discs tire size 15.00-21 TO-3 Weight of the complete wheel 220 kg Basic fuel consumption 65.2 l / 100km Maximal speed 80 km / h Permanent drive 8 x 8 Max. tensile force 117.7 kN Rope length 85 m
